| Parameter | |
| Model | YDK-139-185-6 (T1126) |
| Horsepower | 1/4 hp (185w) |
| Nameplate Speed | 1075 rpm |
| Number of Speed | 1 |
| Phase | Single |
| Voltage | 208-230V AC |
| Frequency | 60Hz |
| Ins. Class | B |
| Motor Shaft Rotation | CWSE |
| Capacitor | 6 μF 450VAC |
| Dimensions | |
| Shaft | 1/2″ x 3.88″ (12.7 x 98.5 mm) |
| Motor Diameter | 5-5/8″ (143 mm) |
| Motor length less shaft | 106 mm |
| Mounting Bolt Pattern | Diameter 5.2″ ( 132mm) |
| Application | |
| Motor Usage | HVAC, Condenser Motor, Outdoor Fan Motor etc. |
| Cross reference | Replacement motor fit for K55HXKEA-2430, 0131M00061SP, B13400271S and obsolete part numbers 0131M00014P, 0131M00014PS, and 0131M00061S |
