| Parameter | |
| Model | YSF-150-4 (T839) |
| Horsepower | 150W |
| Nameplate Speed | 1400 rpm |
| Number of Speed | 1 |
| Phase | Single-phase |
| Voltage | 380V AC |
| Frequency | 50Hz |
| Current | 0.37A |
| Ins. Class | F |
| Protection | IP44 |
| Motor Shaft Rotation | CWSE |
| Dimensions | |
| Shaft Diameter | 14mm |
| Shaft Length | 168mm |
| Motor Diameter | 143mm |
| Motor length less shaft | 113mm |
| Mounting center pattern | 60x100mm (Installation hole 4-7x14mm) |
| Application | |
| Motor Usage | High Temperature air conditioner motors. |
